Why does my transformer keep blowing? why does the transformer keeps blowing? why transformers blow? In the world of power distribution and transmission, few events are as potentially dangerous and destructive as a blown transformer. This article will explain why do transformers blow and what to do when a transformer blows.
Figure 1 what causes a transformer to blow?
What is a transformer explosion?
Figure 1-1 explosion of transformer
A transformer explosion is a catastrophic accident that occurs when a transformer is in operation due to internal influences or external influences. In a explosion of transformer, the electrical energy built up inside the transformer is rapidly released, usually accompanied by a loud bang or a series of explosions. This release of energy causes structural damage to the transformer, with transformer fragments flying in all directions. The intense heat generated may start a fire. Further exacerbating the situation and posing a significant threat to buildings, infrastructure, and personnel in the surrounding area. Transformer blowing up can cause a very large amount of economic damage.
Why does a transformer blow?
Figure 1-2 why do transformers blow up
We as electrical industry practitioners, we all have a great curiosity about the causes of exploded transformer, what actually causes the transformer blew up? what makes a transformer blow?
Next, we will show real cases in shinenergy practice to reveal the causes of transformer blowing at night for you one by one:
How does a transformer blow? Internal factors leading to transformer exploding:
Figure 1-3 transformers blowing
Overloading causes the transformer to explode
The customer of shinenergy, which is involved in photovoltaic power generation, placed an order for a transformer with a rated capacity of 1,000kVA to convert the DC power generated by the solar panels into AC power and transmit it to the grid.
Initially, the power station was designed for an installed capacity of 800kW and the transformer was working fine. The maintenance team inspected the transformer electric components to ensure there were no signs of wear that could lead to a power outage. However, the power station decided to expand and upgrade the capacity by adding more solar panels, bringing the total installed capacity to 1,200 kW. During the expansion, the transformer was overloaded for a long period of time.
The transformer, which was originally rated at 1000kVA, had to carry a load of 1200kW for a long period of time. The load on the transformer was continuously high. After several months of continuous operation, a slight burning odor could already be detected in the vicinity of the transformer.
This indicates that the insulation inside the blown transformer fuse blown may have been damaged to some extent. Eventually, the insulation of the transformer was severely degraded, leading to a partial short circuit fault where the transformer fire into flames, which was fortunately detected in time without too much damage. After the transformers blast off, emergency services were on high alert, quickly responding to the scene.
Figure 1-4 exploded transformer
Insulation failure leads to transformer blows up
why would a transformer blow? As we learned in the real-life example above, when a transformer is overloaded causing the temperature of the transformer’s operating environment to exceed its designed temperature rise range, the transformer’s insulating paper can burn and become damaged. Therefore, insulation within the transformer is critical to prevent arcing between different transformer components. Over time, the insulation may deteriorate due to factors such as damage, aging, moisture intrusion or chemical exposure. Once the insulation fails, arcing can occur, generating intense heat and potentially leading to blowing transformer.
Figure 1-5 transformers blowing
Manufacturing defects cause transformers blowing up
what makes transformers blow? Sometimes transformers produced by some irresponsible manufacturers may have inherent manufacturing defects that can affect their performance and reliability. These defects may include faulty winding connections, substandard insulation or improper assembly, all of which increase the risk of trafo explosion.
Figure 1-6 blow transformer
Power surges cause exploding electrical transformer
what does it mean when a transformer blows?Voltage surges in the grid, whether from lightning or other sources, can place excessive stress on the insulation and components of a transformer, leading to a potential exploding electrical transformer.
External factors leading to electric transformer explosions:
Lightning strikes cause current transformer explosions:
why do power transformers blow? Substations are often vulnerable to lightning strikes. A direct hit or a nearby lightning strike can generate very high voltages and currents in a transformer, overwhelming its protection system and causing fusing.
Short circuits cause transformers to explode:
Figure 1-7 why do transformers blow
why do electrical transformers blow up? Internal or external short circuits can cause large amounts of current to flow through a transformers blowing up The sudden increase in current generates excessive heat, damaging the windings and causing fusing.
Other external factors cause transformers to explode:
Figure 1-8 electrical transformer explosion
what causes a transformer to blow up? Things such as vibration, mechanical stress or poor maintenance can also cause transformers to fail. For example, vibrations from nearby machinery or transport can loosen connections and cause internal damage over time, leading to electrical transformer explosion.
what happens when a transformer blows?
Figure 2-1 transformer blowing up
LOOK: what does a blown transformer look like?
What happens if a transformer blows？ A transformer blow up may produce a transformer blowing up green, a transformer blowing up blue light and an transformer blew up orange flame. exploding electrical transformer blue flame may be: if the environment around the transformer there is incomplete combustion, such as combustion of carbon monoxide continues to burn, the flame may also appear blue.When we saw the blown transformer smoke ring, we knew immediately that there had been a significant electrical incident.
power transformer explosion green flame may be:Transformer internal contains copper parts, if in the combustion process, copper and some substances have a chemical reaction, it may produce green flame. Transformer holding an orange flame may be the general situation of the flame state
LISTEN: What does it sound like when a transformer blows?
Figure 2-2 what does a transformer sound like when it blows
what does a transformer blowing sound like? When a blown up transformer, it can create a loud, startling sound. does a transformer blowing sound like a gunshot?The exact sound depends on the cause and severity of the failure, but common descriptions include:
- Loud Bang or Boom (transformer blowing up sound): This is the most typical transformer explosion sound, similar to a firecracker or a small electric transformers exploding today, and it can often be heard from a significant distance. The sound of a blown transformer near me is often described as a loud bang, followed by a series of crackling noises.
- Humming or Buzzing(transformer explosion sound): Before the transformer blown up, you might notice an increase in humming or buzzing transformeras the transformer struggles with electrical stress.
- Sizzling or Crackling: transformer explosion soundmight accompany arcing or sparking inside the transformer, especially during insulation failure or short-circuiting.
- Popping or Whining: Electricity transformer explosionnoises can occur if the failure is less dramatic or due to a gradual buildup of pressure within the transformer.
- Hissing: If oil or gas escapes from a pressurized transformer, it might make a hissing transformer blowing up sound.
- Electrical Arcing: You might hear a sharp, crackling transformer exploding sound from electricity discharging.
How do we deal with transformer explosions?
Figure 3-1 blown up transformer
In the event of a transformer exploding, The transformer explosion near me was a reminder of how important it is to have an emergency preparedness plan in place. I was heading home from work when I saw a huge flash and heard an electrical explosions; a transformer blew near me, and it was quite a sight. The following emergency measures should be taken immediately:
- Evacuate Personnel: Ensure that all personnel are immediately evacuated to a safe area to avoid injury from transformer blew outdebris or fire.
- Disconnect Power: If possible, immediately disconnect power to the transformers on power linesto prevent further damage and fire.
- Call the Police: Immediately contact the fire department and power company to report the transformer explodesand request emergency assistance.
- Establish a Cordon Area: Establish a cordon area around the accident site to prevent uninvolved persons from entering until professionals arrive at the scene.
- Document the scene: If it is safe to do so, record photos and video of the accident scene for subsequent accident investigations and insurance claims.
How long does it take to fix a transformer?
Figure 4-1 how long to fix a blown transformer?/transformer blew
How long does it take to fix a transformer? The time it takes to fix an exploded transformer depends on a number of factors, including:
- Degree of damage: HOW LONG TO FIX A TRANSFORMER? The severity of the damage to the transformer will have a direct impact on the repair time.
- Spare parts availability: How long does it take to fix a blown? Whether there are spare transformer blew how long to fix or parts available and how long they will take to transport?
- Repair crews: how quickly repair crews arrive at the site and how efficiently they work.
- Accident investigation: The accident investigation may take some time to determine the cause of the explosion. Which may affect the start of the repair work.
Who do you call when a transformer blows?
Figure 5-1 did a transformer blow near me
If a transformer explodes, here are the people or organizations you should contact:
Fire department
How long does it take to repair a blown transformer？ The transformer blew up near me. Immediately call the emergency number and request help from the fire department to extinguish any possible fires.
power company
who to call if a transformer blows? A blown power line transformer can cause significant disruptions to the electrical supply in the affected area. power outage due to transformer blew. Contact your local power company to report the transformer explosion today. It asks them to disconnect the power to prevent further damage.
Insurance Company
who to call when a transformer blows? If your property or business has been affected, contact your insurance company to report the incident and begin the claims process.
Professional Repair Services
Contact a professional transformer repair service to assess the damage and make the necessary repairs. The insurance report highlighted the financial impact of transformers blowing and the need for better protective measures.
Who to call when transformer blows? Depending on local laws, such accidents may need to be reported to the safety regulators for accident investigation and preventive measures. The transformer power outage affected thousands of homes, prompting the utility company to dispatch emergency repair crews immediately.
Who do you call if a transformer blows? Remember, safety always comes first. When dealing with an exploding transformer, make sure you follow all safety protocols and let the professionals handle the accident scene . Following the transformer outage, the local utility company worked overnight to restore power.
How can we prevent transformer explosions?
Figure 6-1
To prevent transformer exploded, we’ve got to approach it from a few different angles. Regular maintenance is crucial, just like changing the oil in your car. It keeps everything running smoothly and catches potential issues before they become big problems. We also need to monitor the load on transformers to avoid overloading them. It’s like not asking your car to pull a load it’s not designed for. Keeping the temperature in check is another important aspect. Overheating can cause the insulation to break down, leading to short circuits and potential transformers explosions, much like how an engine can seize up if it gets too hot.
High-quality insulation is a must, as it can handle higher voltages and reduce the risk of short circuits. When it comes to weather, especially thunderstorms, we should have lightning protection to safeguard transformers from being struck. Short-circuit protection is also essential. It’s like having a parachute in case something goes wrong, allowing the transformer to cut power quickly and avoid a catastrophic failure. The liner power transformer’s efficiency has been improved with the latest cooling technology, reducing the risk of overheating.
Purchasing transformers from reputable manufacturers is key. It’s not the place to cut corners. We also need to ensure transformers are in environments that won’t cause them to corrode or degrade, similar to how you wouldn’t leave a car out in the elements without protection. Proper training for those who operate and maintain transformers is non-negotiable. It’s like ensuring your mechanic knows how to fix your car correctly.
FQA
What does it look like when a transformer blows?
When a transformer blows, it typically results in a loud explosion, often accompanied by a bright flash of light and possibly a fire. It can also cause power outages in the surrounding area.
What happens when transformer blows?
When a transformer blows, it usually results in a loud noise and a bright flash, and it can cause a power outage in the surrounding area.
How long to restore power after transformer blows
How long will power be out if a transformer blows? The time to restore power after a transformer explosion can vary significantly. It depends on several factors, including the severity of the damage, the complexity of the restoration work, and the availability of resources and equipment. It can take anywhere from a few hours to several days or even longer in some cases.
Why do transformers blow during storms?
- Lightning Strikes: Direct hits or nearby strikes can cause extreme voltage surges that exceed the transformer’s insulation capabilities, leading to explosions.
- High Winds and Debris: Strong winds can knock down trees or other objects that crash into transformers or power lines. It causes short circuits or physical damage that may lead to a transformer blowing.
- Flooding: Water can cause electrical shorts and damage the transformer’s insulation, leading to failures.
- Overload: Storms can lead to increased demand for electricity for heating or cooling. Which can overload transformers if they are not designed to handle the extra load
